Chicago Transit -> CTA -> Brown Line / Purple Line / Red Line
Belmont


Brown Line

Year Opened 1900 (rebuilt 2008) # of Tracks 4
Rail Transfers Brown/Purple/Red
Platform Layout 2 island platforms Park-n-Ride No
City Chicago Right of Way Alley
Point of Interest

Belmont is a very busy location for the Brown Line. Just north of this station the Brown Line diverges from the 4-track mainline onto its own 2-track 'L' to Kimball. Outbound trains must cross all 4 tracks at grade which can easily tie up rush hour Red and Purple Line trains. In 2008 the station renovation was completed with much wider platforms.

Click on any photo to enlarge!

chi-hr-br-belmont-042505-02.jpg (62194 bytes)If you look in the distance you can see an outbound train crossing over all the tracks on its way to Kimball (4/25/05) From the old cross-over, no longer there (4/25/05)
chi-hr-br-belmont-042505-04.jpg (68455 bytes)Outbound train at Belmont. Note how close the building is to the tracks. (4/25/05) chi-hr-br-belmont-042505-01.jpg (56883 bytes)Looking south from Belmont. (4/25/05)
The new wider platforms (8/31/11) The new wider platforms (8/31/11)
chi-hr-rd-belmont-042505-02.jpg (67016 bytes)Northbound train. (4/25/05) chi-hr-rd-belmont-042505-06.jpg (47529 bytes)Sears Tower visible in the distance. (4/25/05)
chi-hr-rd-belmont-042505-01.jpg (62225 bytes)Northbound red line train on right, work train on left. (4/25/05) chi-hr-rd-belmont-042505-05.jpg (72714 bytes)Two car non-revenue train entering platform (4/25/05)

NEXT STOP

Towards Kimball (Brown) Towards Loop (Brown)

Southport

Wellington

Towards Linden (Purple) Towards Loop (Purple)

Howard (Ballgames: Sheridan)

Wellington

Towards Howard (Red) Towards 95/Dan Ryan (Red)

Addison

Fullerton
